Vertical Vibration High Frequency Electrodynamics Vibration Tester with 51mm Displacement

1
MOQ
$25,000
価格
Vertical Vibration High Frequency Electrodynamics Vibration Tester with 51mm Displacement
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
正確さ: ±5%
電圧: 380V
最大。スピード: 1.6m/秒
変位: 51mm
振動波: サイン、ランダム、ショック
振動方向: 縦振動
力: 20kw
保護クラス: IP55
冷却方法: 空冷
周波数範囲: 3-3500hz
定数加速: 1000m/s2
最高。ローディング: 100kg
可動コイル重量: 3.5kg
コイルの寸法の移動: Φ150mm
定格正弦力: 3000N
ハイライト:

Vertical vibration tester with 51mm displacement

,

High frequency electrodynamics vibration shaker

,

Vibration shaker system with high displacement

基本情報
起源の場所: 広東省、中国
ブランド名: ASLI
お支払配送条件
製品の説明
Vertical Vibration High Frequency Electrodynamics Vibration Tester A high-frequency vibration test system—also known as an electromagnetic high-frequency vibration table or swept-frequency vibration tester—uses electromagnetic force to drive a platform and generate controlled vibrations. This equipment simulates vibration environments that products encounter during manufacturing, transportation, and actual use, enabling comprehensive testing of reliability, structural
