| Model | TS-42(A~C) | TS-80(A~C) | TS-150(A~C) | TS-252(A~C) | TS-450(A~C) |
|---|---|---|---|---|---|
| Internal Dimension W×H×D (mm) | 400×350×350 | 500×400×400 | 600×500×500 | 700×600×600 | 800×750×750 |
| External Dimension W×H×D (mm) | 1400×1800×1400 | 1550×1950×1550 | 1600×2000×170 | 1700×2100×1750 | 1800×2200×1900 |
| Temperature Range |
Type A: -40°C to +150°C (200°C optional) Type B: -55°C to +150°C (200°C optional) Type C: -65°C to +150°C (200°C optional) |
||||
| Exposure Time |
High Temperature: +60°C to +150°C (200°C optional) - 30 minutes Low Temperature: -10°C to -40°C/-55°C/-65°C - 30 minutes |
||||
| Temperature Recovery/Conversion Time | ≤5 minutes / ≤5 seconds | ||||
| Control Accuracy/Distribution Uniformity | ±0.5°C / ±2°C | ||||
| Construction Materials |
Inner box: SUS 304# stainless steel Outer box: Stainless steel or SEE cold-rolled steel with paint coating |
||||
| Insulation Material | High temperature resistant, high density formate chlorine ethyl acetum foam | ||||
| Cooling System |
Semi-hermetic double-stage compressor (water-cooled type) Hermetic double-stage compressor (air-cooled type) |
||||
| Power | AC220V, 50/60Hz or AC380V, 50/60Hz | ||||
| Weight (Approx. kg) | 450 | 600 | 750 | 950 | 1200 |
